TS153 System

Sliding Door & Window

downloaded (32)

Description

TS153 System

Thermal Break
Sliding Door & Window

Product code: TS153
Frame width: 168 mm
Sash width: 70 mm
Wall thickness: 2 – 2.2 mm
Glass thickness: 28 to 52 mm
Polyamide size: 18 – 24 – 38 mm
Thermal conductivity: Uf: 3.2w/m2k
Appearance: Flat and smooth from the outside and inside
Type of corner fixture: Riveted
EPDM identification and sealing gaskets
Possibility to install European fittings Lift and slide 300- 400 kg
Type of opening: lift and slide with normal opening
